High Torque in an even smaller package

Torque QTR 65 range and QTR 78 range

Almelo, The Netherlands, September 2017 – Tecnotion introduces a new series of smaller QTR torque motors at the SPS IPC Drives 2017. A new 65 mm and 78 mm diameter motor makes the quality and torque of the Tecnotion QTR series motor available for even smaller applications.

Central in the development of the new 65 and 78 mm motors is the low axial height and high torque density, known as existing Tecnotion QTR motors. A special rotor design allows for a large inner diameter. This makes it possible to use hollow axles, even for the QTR 65 motor. Four different stator heights are available for each diameter. The small QTR motors therefore suit a wide variety of markets including semiconductor, medical, machine tooling, and robotics.

QTR 65 and QTR 78 motors have a brushless design. No mechanical transmission is needed. Torque ranges from 0.3-2.3 Nm continuous for QTR 65 and 0.6-4.7 Nm continuous for QTR 78. Speed ranges from 410-6200 rpm at just 48 volts.

To provide maximum flexibility and integration the QTR 65 and QTR 78 use flying leads instead of a power cable.
